Step 4. Connect the cables to the backplane.
Step 5. Install the air baffle into the rear drive cage as shown.
Figure 121. Air baffle installation
a.
Align the air baffle edge with the notch on the drive cage.
b.
Press the air baffle down and make sure that it is seated in place.
Step 6. Align the pins on the rear drive cage with the corresponding hole and slot in the chassis. Then,
lower the rear drive cage into the chassis until it is fully seated.
Figure 122. Hot-swap rear drive cage installation
Step 7. Connect the cables to the system board or expansion slots. See
Chapter 6 “Internal cable routing”
on page 217.
Chapter 5. Hardware replacement procedures 173
