Configurations 100G PCIe adapters
10 x 2.5" NVMe
10 x 2.5" AnyBay
8 x2.5'' SAS/SATA
6 x SAS/SATA + 4 x AnyBay
ThinkSystem Broadcom 57508 100GbE QSFP56 2-
port PCIe 4 Ethernet Adapter V2 w/ Active Fiber
cables
Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port
x16 PCIe 3.0 HCA w/ Tall Bracket L1/SBB w/ Active
Fiber cables
Mellanox ConnectX-6 HDR100 IB/100GbE VPI 2-port
x16 PCIe 3.0 HCA w/ Tall Bracket L1/SBB w/ Active
Fiber cables
Mellanox ConnectX-6 HDR IB/200GbE Single Port
x16 PCIe Adapter w/ Tall Bracket w/ Active Fiber
cables
ThinkSystem Mellanox ConnectX-6 Dx 100GbE
QSFP56 2-port PCIe Ethernet Adapter w/ Active
Fiber cables
ThinkSystem NVIDIA ConnectX-7 NDR400 OSFP 1-
port PCIe Gen5 Adapter w/ Active Fiber cables
ThinkSystem Nvidia ConnectX-7 NDR200/HDR
QSFP112 2-port PCIe Gen5 x16 InfiniBand Adapter
w/ Active Fiber cables
Technical rules for drives
Use this section to understand the technical rules for drives.
Drive installation rules
The following rules for drives provide information necessary for installing a drive.
General rules
1. The drive bays are numbered to indicate the installation order (starting from number “0”). Follow the
installation order when you install a drive. See
“Front view” on page 17.
2. The drives in a single RAID array must be of the same type (as in hard disk drives (HDD), solid-state
drives (SSD), and so on), same size, and same capacity.
3. If your server comes with rear drives, always install the rear backplane first. The drive installation should
be rear drive bay 16 17, and then front drive bay 0 1 2 3 4 5 6 7 8 9.
4. The suggested priority of different drive types: NVMe SSDSAS SSDSATA SSDSAS HDDSATA
HDD.
5. The installation order of different drive interface types: NVMe SAS SATA.
6. For EDSFF drives, follow the numerical order of the drive bay sequence. Do not skip bays when installing
EDSFF drives.
Mixing rules
1. You can use drives from different vendors.
2. You can mix drives of different types and different capacities in one system, but not in one RAID array.
And when you deploy a drive mix, install drives of lower capacity first.
3. When mixing NVMe/SAS/SATA drives in one system, install NVMe drives in a descending bay sequence
order, 9 8 7...; and SAS/SATA drives in an ascending bay sequence order, 0 1 2....
Chapter 5. Hardware replacement procedures 53
