System Environmental Information
Sub Menu
Example
• Ambient temperature
• Exhaust temperature
• CPU temperature
• PSU status
• Spinning speed of fans by RPM
Ambient Temp: 24 C
Exhaust Temp: 30 C
CPU1 Temp： 50 C
PSU1: Vin= 213 w
Inlet= 26 C
FAN1 Front: 21000 RPM
FAN2 Front: 21000 RPM
FAN3 Front: 21000 RPM
FAN4 Front: 21000 RPM
Active Sessions
Sub Menu
Example
Quantity of active sessions
Active User Sessions: 1
Actions
Sub Menu
Example
Several quick actions are available:
• Restore XCC to Defaults
• Force XCC Reset
• Request XCC Reset
• Set UEFI Memory Test
• Clear CMOS
• Request Virtual Reseat
• Modify XCC Static IPv4 Address/Net mask/Gateway
• Modify System Name
• Generate/Download FFDC Service Data
Request XCC Reset?
This will request the BMC to reboot itself.
Hold √ for 3 seconds
Integrated diagnostics panel
The integrated diagnostics panel is attached to the front of the server, while it allows quick access to system
information such as errors, system status, firmware, network, and health information.
306
ThinkSystem SR635 V3 User Guide
