7mm drive backplane
This section provides cable routing information for the 7mm drives.
For the locations of connectors on the processor board, refer to
“System-board-assembly connectors” on
page 33
.
Figure 177. Cable routing for 7mm SATA drives
Chapter 6. Internal cable routing 235
