Figure 139. Assembling the serial port module
a.
Align the two screw holes on the cable connector to the bracket.
b.
Install the two screws to the bracket.
Step 3. Install the serial port module to the riser bracket.
Figure 140. Installing the serial port module
a.
Open the retention latch on the riser cage.
b.
Install the serial port module to the riser bracket.
c.
Close the retention latch and ensure that the serial port module is securely installed.
Step 4. Install the riser assembly to the server.
