a. Remove the screws.
b.
Remove the bracket from the chassis as shown.
Note: The illustrations show removing the A1, B1, and C1 rearwall brackets. The procedure is the
same for removing other rearwall brackets.
Figure 176. A1 rearwall bracket removal (left)
Figure 177. B1 rearwall bracket removal (middle)
210 ThinkSystem SR650 V3 User Guide
