– “Two 8 x SAS/SATA backplanes” on page 307
– “Two 8 x AnyBay backplanes (Gen 4)” on page 311
– “Two 8 x NVMe backplanes (Gen 4)” on page 315
– “One 8 x SAS/SATA and one 8 x AnyBay (Gen 4) backplanes” on page 317
– “One 8 x SAS/SATA and one 8 x NVMe (Gen 4) backplanes” on page 323
– “One 8 x AnyBay and one 8 x NVMe backplanes (Gen 4)” on page 329
• Three front backplanes:
–
“Three 8 x SAS/SATA backplanes” on page 333
– “Three 8 x AnyBay backplanes” on page 382
– “Three 8 x NVMe backplanes (Gen 4)” on page 384
– “One 8 x AnyBay and two 8 x NVMe backplanes (Gen 4)” on page 387
– “One 8 x SAS/SATA and two 8 x NVMe (Gen 4) backplanes” on page 389
– “Two 8 x SAS/SATA and one 8 x AnyBay (Gen 4) backplanes” on page 392
– “Two 8 x SAS/SATA and one 8 x NVMe (Gen 4) backplanes” on page 408
– “24 x 2.5" SAS/SATA expander backplane” on page 411
One 8 x SAS/SATA backplane
This section provides cable routing information for the server model with one 8 x 2.5-inch SAS/SATA front
drive backplane.
To connect power cables for the front backplane(s), refer to
“Backplanes: server models with 2.5-inch front
drive bays” on page 297
.
To connect signal cables for the front backplane(s), refer to the following cable routing scenarios depending
on your server configuration.
•
“Onboard connectors” on page 299
• “8i/16i RAID/HBA adapter” on page 300
• “CFF 8i/16i RAID/HBA adapter” on page 301
Onboard connectors
The following shows the cable connections for the 8 x 2.5-inch SAS/SATA configuration with onboard
connectors.
Connections between connectors:
1 ↔ 1 , 2 ↔ 2 , 3 ↔ 3 , ... n ↔ n
Chapter 6
. Internal cable routing 299
