Figure 250. RAID cable routing
From To
1 Signal connector on the 7mm drive backplane 8i adapter: C0
Front I/O connectors
Use the section to understand the cable routing for the front I/O connectors, including VGA connector,
external diagnostics connector, front operator panel connector, and front USB connectors.
•
“Front I/O connectors on rack latches” on page 279
• “Front I/O connectors on the media bay” on page 280
Front I/O connectors on rack latches
Note: When routing a cable on the rack latch, ensure that it is fixed on the upper frame of the cable retainer.
For details, refer to .
Chapter 6. Internal cable routing 279
