Lenovo ThinkSystem SR650 V3 7D75 - Page 273

Figure 227. Removing the riser bracket
Step 5. Remove the serial port module out of the riser bracket.
Figure 228. Removing the serial port module
a.
Press down the bracket latch.
b.
Open the latch.
c.
Slide the serial port module out of the riser bracket.
Step 6. (Optional) If you need to replace the serial port bracket, use a 5 mm wrench to disassemble the
serial port cable from the bracket.
Chapter 5. Hardware replacement procedures 263
