SAS/SATA cable routing
Figure 286. SAS/SATA cable routing to CFF RAID/HBA adapter
From To
1 Backplane 1: SAS CFF adapter
• C0
• C1
2 CFF adapter: MB (CFF input) Onboard: PCIe 4
3 CFF adapter: PWR Onboard: CFF RAID/HBA PWR
Chapter 6. Internal cable routing 305
