Address Designaon Default seng Category Data type Factor A M
0x232F:015
(P585.15)
Modbus diagnoscs of last Tx data: Data byte 13 - (Read only) Modbus RTU U8 1 - -
0x232F:016
(P585.16)
Modbus diagnoscs of last Tx data: Data byte 14 - (Read only) Modbus RTU U8 1 - -
0x232F:017
(P585.17)
Modbus diagnoscs of last Tx data: Data byte 15 - (Read only) Modbus RTU U8 1 - -
0x2340 PROFIBUS communicaon No acon/no error [0] PROFIBUS U8 1 - -
0x2341:001
(P510.01)
PROFIBUS sengs: Staon address 3 PROFIBUS U8 1 P -
0x2342:001
(P511.01)
Acve PROFIBUS sengs: Acve staon address - (Read only) PROFIBUS U8 1 - -
0x2342:002
(P511.02)
Acve PROFIBUS sengs: Acve baud rate - (Read only) PROFIBUS U8 1 - -
0x2342:003
(P511.03)
Acve PROFIBUS sengs: Watchdog me - (Read only) PROFIBUS U16 1 - -
0x2343
(P509.00)
PROFIBUS switch posion - (Read only) PROFIBUS U16 1 - -
0x2344:001
(P512.01)
PROFIBUS Conguraon: Extended diagnosc bit Delete [0] PROFIBUS U8 1 P -
0x2348:001
(P516.01)
PROFIBUS Status: Bus status - (Read only) PROFIBUS U8 1 - -
0x2348:002
(P516.02)
PROFIBUS Status: Watchdog status - (Read only) PROFIBUS U8 1 - -
0x2349
(P517.00)
PROFIBUS error - (Read only) PROFIBUS U32 1 - -
0x234A:001
(P580.01)
PROFIBUS stascs: Data cycles per second - (Read only) PROFIBUS U32 1 - -
0x234A:002
(P580.02)
PROFIBUS stascs: Parameterizaon events - (Read only) PROFIBUS U32 1 - -
0x234A:003
(P580.03)
PROFIBUS stascs: Conguraon events - (Read only) PROFIBUS U32 1 - -
0x234A:004
(P580.04)
PROFIBUS stascs: Diagnoscs events - (Read only) PROFIBUS U32 1 - -
0x234A:005
(P580.05)
PROFIBUS stascs: C1 messages - (Read only) PROFIBUS U32 1 - -
0x234A:006
(P580.06)
PROFIBUS stascs: C2 messages - (Read only) PROFIBUS U32 1 - -
0x234A:007
(P580.07)
PROFIBUS stascs: Watchdog events - (Read only) PROFIBUS U32 1 - -
0x234A:008
(P580.08)
PROFIBUS stascs: Data exchange aborts - (Read only) PROFIBUS U32 1 - -
0x234A:009
(P580.09)
PROFIBUS stascs: Total data cycles - (Read only) PROFIBUS U32 1 - -
0x2360
(P508.00)
EtherCAT communicaon No acon/no error [0] EtherCAT U8 1 - -
0x2361:004
(P510.04)
EtherCAT sengs: Device idener 0 EtherCAT U16 1 P -
0x2362:004
(P511.04)
Acve EtherCAT sengs: Device idener - (Read only) EtherCAT U16 1 - -
0x2362:006
(P511.06)
Acve EtherCAT sengs: Staon address - (Read only) EtherCAT U16 1 - -
0x2362:007
(P511.07)
Acve EtherCAT sengs: Tx length - (Read only) EtherCAT U16 1 - -
0x2362:008
(P511.08)
Acve EtherCAT sengs: Rx length - (Read only) EtherCAT U16 1 - -
0x2363
(P509.00)
EtherCAT switch posion - (Read only) EtherCAT U16 1 - -
0x2368
(P516.00)
EtherCAT status - (Read only) EtherCAT U16 1 - -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
