Address Designaon Default seng Category Data type Factor A M
0x2369
(P517.00)
EtherCAT error - (Read only) EtherCAT U16 1 - -
0x2380
(P508.00)
PROFINET communicaon No acon/no error [0] PROFINET U8 1 - -
0x2381:001
(P510.01)
PROFINET sengs: IP address 0 PROFINET U32 1 PE -
0x2381:002
(P510.02)
PROFINET sengs: Subnet 0 PROFINET U32 1 PE -
0x2381:003
(P510.03)
PROFINET sengs: Gateway 0 PROFINET U32 1 PE -
0x2381:004
(P510.04)
PROFINET sengs: Staon name PROFINET STRING[240] 1 P -
0x2381:005 PROFINET sengs: I&M1 System designaon PROFINET STRING[32] 1 P -
0x2381:006 PROFINET sengs: I&M1 Installaon site PROFINET STRING[22] 1 P -
0x2381:007 PROFINET sengs: I&M2 Installaon date PROFINET STRING[16] 1 P -
0x2381:008 PROFINET sengs: I&M3 addional informaon PROFINET STRING[54] 1 P -
0x2381:009 PROFINET sengs: I&M4 signature code PROFINET OCTET[54] 1 P -
0x2382:001
(P511.01)
Acve PROFINET sengs: IP address - (Read only) PROFINET U32 1 E -
0x2382:002
(P511.02)
Acve PROFINET sengs: Subnet - (Read only) PROFINET U32 1 E -
0x2382:003
(P511.03)
Acve PROFINET sengs: Gateway - (Read only) PROFINET U32 1 E -
0x2382:004
(P511.04)
Acve PROFINET sengs: Staon name - (Read only) PROFINET STRING[240] 1 - -
0x2382:005
(P511.05)
Acve PROFINET sengs: MAC Address - (Read only) PROFINET OCTET[6] 1 - -
0x2388
(P516.00)
PROFINET status - (Read only) PROFINET U16 1 - -
0x2389:001
(P517.01)
PROFINET error: Error 1 - (Read only) PROFINET U16 1 - -
0x2389:002
(P517.02)
PROFINET error: Error 2 - (Read only) PROFINET U16 1 - -
0x23A0
(P508.00)
EtherNet/IP communicaon No acon/no error [0] EtherNet/IP U8 1 - -
0x23A1:001
(P510.01)
EtherNet/IP sengs: IP address 276605120 EtherNet/IP U32 1 PE -
0x23A1:002
(P510.02)
EtherNet/IP sengs: Subnet 16777215 EtherNet/IP U32 1 PE -
0x23A1:003
(P510.03)
EtherNet/IP sengs: Gateway 0 EtherNet/IP U32 1 PE -
0x23A1:004
(P510.04)
EtherNet/IP sengs: Host name EtherNet/IP STRING[64] 1 P -
0x23A1:005
(P510.05)
EtherNet/IP sengs: IP conguraon BOOTP [1] EtherNet/IP U8 1 P -
0x23A1:006
(P510.06)
EtherNet/IP sengs: Mulcast TTL 1 EtherNet/IP U8 1 P -
0x23A1:007
(P510.07)
EtherNet/IP sengs: Mulcast allocaon Default allocaon [0] EtherNet/IP U8 1 P -
0x23A1:008
(P510.08)
EtherNet/IP sengs: Mulcast IP address 3221373167 EtherNet/IP U32 1 PE -
0x23A1:009
(P510.09)
EtherNet/IP sengs: Mulcast number 1 EtherNet/IP U8 1 P -
0x23A1:010
(P510.10)
EtherNet/IP sengs: Timeout 10000 ms EtherNet/IP U16 1 P -
0x23A2:001
(P511.01)
Acve EtherNet/IP sengs: IP address - (Read only) EtherNet/IP U32 1 E -
0x23A2:002
(P511.02)
Acve EtherNet/IP sengs: Subnet - (Read only) EtherNet/IP U32 1 E -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
