Lenze i55AE155F - Page 672

Address Designaon Default seng Category Data type Factor A M
0x23A2:003
(P511.03)
Acve EtherNet/IP sengs: Gateway - (Read only) EtherNet/IP U32 1 E -
0x23A2:005
(P511.05)
Acve EtherNet/IP sengs: MAC address - (Read only) EtherNet/IP OCTET[6] 1 - -
0x23A2:006
(P511.06)
Acve EtherNet/IP sengs: Mulcast address - (Read only) EtherNet/IP U32 1 E -
0x23A3
(P509.00)
EtherNet/IP switch posion - (Read only) EtherNet/IP U8 1 - -
0x23A4:001
(P512.01)
Port sengs: Port 1 Auto-Negoaon [0] EtherNet/IP U16 1 P -
0x23A4:002
(P512.02)
Port sengs: Port 2 Auto-Negoaon [0] EtherNet/IP U16 1 P -
0x23A5:001
(P519.01)
Acve port sengs: Port 1 - (Read only) EtherNet/IP U16 1 - -
0x23A5:002
(P519.02)
Acve port sengs: Port 2 - (Read only) EtherNet/IP U16 1 - -
0x23A6
(P513.00)
Quality of service - (Read only) EtherNet/IP U8 1 - -
0x23A7
(P514.00)
Address conict detecon Enabled [1] EtherNet/IP U8 1 P -
0x23A8
(P516.00)
CIP module status - (Read only) EtherNet/IP U16 1 - -
0x23A9
(P517.00)
EtherNet/IP status - (Read only) EtherNet/IP U16 1 - -
0x23B0
(P508.00)
Modbus TCP communicaon No acon/no error [0] Modbus TCP U8 1 - -
0x23B1:001
(P510.01)
Modbus -TCP/IP sengs: IP address 276605120 Modbus TCP U32 1 PE -
0x23B1:002
(P510.02)
Modbus -TCP/IP sengs: Subnet 16777215 Modbus TCP U32 1 PE -
0x23B1:003
(P510.03)
Modbus -TCP/IP sengs: Gateway 0 Modbus TCP U32 1 PE -
0x23B1:005
(P510.05)
Modbus -TCP/IP sengs: IP conguraon Stored IP [0] Modbus TCP U8 1 P -
0x23B1:006
(P510.06)
Modbus -TCP/IP sengs: Time-to-live value (TTL) 32 Modbus TCP U8 1 P -
0x23B1:010
(P510.10)
Modbus -TCP/IP sengs: Ethernet me-out 10 s Modbus TCP U16 1 P -
0x23B1:011
(P510.11)
Modbus -TCP/IP sengs: Secondary port 502 Modbus TCP U16 1 P -
0x23B2:001
(P511.01)
Acve Modbus TCP sengs: Acve IP address - (Read only) Modbus TCP U32 1 E -
0x23B2:002
(P511.02)
Acve Modbus TCP sengs: Acve subnet - (Read only) Modbus TCP U32 1 E -
0x23B2:003
(P511.03)
Acve Modbus TCP sengs: Acve gateway - (Read only) Modbus TCP U32 1 E -
0x23B2:005
(P511.05)
Acve Modbus TCP sengs: MAC address - (Read only) Modbus TCP OCTET[6] 1 - -
0x23B3
(P509.00)
Switch posion - (Read only) Modbus TCP U8 1 - -
0x23B4:001
(P512.01)
Port sengs: Port 1 Auto-Negoaon [0] Modbus TCP U16 1 P -
0x23B4:002
(P512.02)
Port sengs: Port 2 Auto-Negoaon [0] Modbus TCP U16 1 P -
0x23B5:001
(P513.01)
Acve port sengs: Port 1 - (Read only) Modbus TCP U16 1 - -
0x23B5:002
(P513.02)
Acve port sengs: Port 2 - (Read only) Modbus TCP U16 1 - -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
672
