Address Designaon Default seng Category Data type Factor A M
0x23B6:001
(P514.01)
Time-out monitoring: Time-out me 2.0 s Modbus TCP U16 10 P -
0x23B6:002
(P514.02)
Time-out monitoring: Keep alive me-out me 2.0 s Modbus TCP U16 10 P -
0x23B6:005
(P514.05)
Time-out monitoring: Keep alive register 0 Modbus TCP U16 1 K r
0x23B8
(P516.00)
Modbus TCP module status - (Read only) Modbus TCP U16 1 - -
0x23B9
(P517.00)
Modbus TCP/IP network status - (Read only) Modbus TCP U16 1 - -
0x23BA:001
(P580.01)
Modbus TCP stascs: Messages received - (Read only) Modbus TCP U32 1 - -
0x23BA:002
(P580.02)
Modbus TCP stascs: Valid messages received - (Read only) Modbus TCP U32 1 - -
0x23BA:003
(P580.03)
Modbus TCP stascs: Messages with excepons - (Read only) Modbus TCP U32 1 - -
0x23BA:005
(P580.05)
Modbus TCP stascs: Messages sent - (Read only) Modbus TCP U32 1 - -
0x23BB:001 ...
0x23BB:024
(P530.01 ... 24)
Modbus TCP/IP parameter mapping: Parameter 1 ...
Parameter 24
0x00000000 Modbus TCP IDX 1 PH -
0x23BC:001 ...
0x23BC:024
(P531.01 ... 24)
Register assignment: Register 1 ... Register 24 - (Read only) Modbus TCP U16 1 - -
0x23BD
(P532.00)
Vericaon code - (Read only) Modbus TCP U16 1 - -
0x23BE:001
(P585.01)
Modbus TCP/IP diagnoscs of last Rx/Tx data:
Receive oset
0 Modbus TCP U8 1 - -
0x23BE:002
(P585.02)
Modbus TCP/IP diagnoscs of last Rx/Tx data: Last
Rx message
- (Read only) Modbus TCP OCTET[64] 1 - -
0x23BE:003
(P585.03)
Modbus TCP/IP diagnoscs of last Rx/Tx data: Trans-
mit oset
0 Modbus TCP U8 1 - -
0x23BE:004
(P585.04)
Modbus TCP/IP diagnoscs of last Rx/Tx data: Last
Tx message
- (Read only) Modbus TCP OCTET[64] 1 - -
0x23C0 POWERLINK communicaon No acon/no error [0] POWERLINK U8 1 - -
0x23C1:004 POWERLINK sengs: Node ID 0 POWERLINK U8 1 - -
0x23C2:001 Acve POWERLINK sengs: IP address - (Read only) POWERLINK U32 1 E -
0x23C2:002 Acve POWERLINK sengs: Subnet - (Read only) POWERLINK U32 1 E -
0x23C2:003 Acve POWERLINK sengs: Gateway - (Read only) POWERLINK U32 1 E -
0x23C2:004 Acve POWERLINK sengs: Node ID - (Read only) POWERLINK U8 1 - -
0x23C2:005 Acve POWERLINK sengs: MAC Address - (Read only) POWERLINK OCTET[6] 1 - -
0x23C2:007 Acve POWERLINK sengs: Tx length - (Read only) POWERLINK U16 1 - -
0x23C2:008 Acve POWERLINK sengs: Rx length - (Read only) POWERLINK U16 1 - -
0x23C3 POWERLINK switch posion - (Read only) POWERLINK U8 1 - -
0x23C8:001 POWERLINK status: Network management - (Read only) POWERLINK U16 1 - -
0x23C9:001 POWERLINK error: Error - (Read only) POWERLINK U16 1 - -
0x2440 Iniate WLAN No acon/no error [0] WLAN U8 1 - -
0x2441:001 WLAN sengs: IP address 28485824 WLAN U32 1 PE -
0x2441:002 WLAN sengs: Netmask 16777215 WLAN U32 1 PE -
0x2441:003 WLAN sengs: Gateway 28485824 WLAN U32 1 PE -
0x2441:004 WLAN sengs: DHCP Enabled [1] WLAN U8 1 P -
0x2441:005 WLAN sengs: DHCP start address 0 WLAN U32 1 PE -
0x2441:006 WLAN sengs: WLAN operaon mode Access point mode [0] WLAN U8 1 P -
0x2441:007 WLAN sengs: WLAN SSID i5 WLAN STRING[32] 1 P -
0x2441:008 WLAN sengs: WLAN password password WLAN STRING[64] 1 P -
0x2441:009 WLAN sengs: WLAN security WPA2 [1] WLAN U8 1 P -
0x2441:010 WLAN sengs: WLAN access Enabled (WLAN on) [1] WLAN U8 1 P -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
