Address Designaon Default seng Category Data type Factor A M

0x2441:011 WLAN sengs: WLAN channel Channel 1 [1] WLAN U8 1 P -

0x2441:012 WLAN sengs: WLAN SSID broadcast Acvated [0] WLAN U8 1 P -

0x2442:001 Acve WLAN sengs: Acve IP address - (Read only) WLAN U32 1 E -

0x2442:002 Acve WLAN sengs: Acve netmask - (Read only) WLAN U32 1 E -

0x2442:003 Acve WLAN sengs: Acve gateway - (Read only) WLAN U32 1 E -

0x2442:004 Acve WLAN sengs: Acve module mode - (Read only) WLAN U8 1 - -

0x2442:005 Acve WLAN sengs: MAC address - (Read only) WLAN OCTET[6] 1 - -

0x2448:001 WLAN status: Connecon me - (Read only) WLAN U32 1 - -

0x2448:002 WLAN status: Number of connecons - (Read only) WLAN U16 1 - -

0x2448:003 WLAN status: Rx frame counter - (Read only) WLAN U16 1 - -

0x2448:004 WLAN status: Error stascs - (Read only) WLAN U16 1 - -

0x2449 WLAN error - (Read only) WLAN U16 1 - -

0x24E0:000 Generic RPDO mapping: Highest subindex 2 Mapping U8 1 PI -

0x24E0:001 Generic RPDO mapping: Entry 1 0x60400010 Mapping U32 1 PH -

0x24E0:002 Generic RPDO mapping: Entry 2 0x60420010 Mapping U32 1 PH -

0x24E0:003 Generic RPDO mapping: Entry 3 0x00000000 Mapping U32 1 PH -

0x24E0:004 Generic RPDO mapping: Entry 4 0x00000000 Mapping U32 1 PH -

0x24E0:005 Generic RPDO mapping: Entry 5 0x00000000 Mapping U32 1 PH -

0x24E0:006 Generic RPDO mapping: Entry 6 0x00000000 Mapping U32 1 PH -

0x24E0:007 Generic RPDO mapping: Entry 7 0x00000000 Mapping U32 1 PH -

0x24E0:008 Generic RPDO mapping: Entry 8 0x00000000 Mapping U32 1 PH -

0x24E0:009 Generic RPDO mapping: Entry 9 0x00000000 Mapping U32 1 PH -

0x24E0:010 Generic RPDO mapping: Entry 10 0x00000000 Mapping U32 1 PH -

0x24E0:011 Generic RPDO mapping: Entry 11 0x00000000 Mapping U32 1 PH -

0x24E0:012 Generic RPDO mapping: Entry 12 0x00000000 Mapping U32 1 PH -

0x24E0:013 Generic RPDO mapping: Entry 13 0x00000000 Mapping U32 1 PH -

0x24E0:014 Generic RPDO mapping: Entry 14 0x00000000 Mapping U32 1 PH -

0x24E0:015 Generic RPDO mapping: Entry 15 0x00000000 Mapping U32 1 PH -

0x24E0:016 Generic RPDO mapping: Entry 16 0x00000000 Mapping U32 1 PH -

0x24E1:000 Generic TPDO mapping: Highest subindex 3 Mapping U8 1 PI -

0x24E1:001 Generic TPDO mapping: Entry 1 0x60410010 Mapping U32 1 PH -

0x24E1:002 Generic TPDO mapping: Entry 2 0x60440010 Mapping U32 1 PH -

0x24E1:003 Generic TPDO mapping: Entry 3 0x603F0010 Mapping U32 1 PH -

0x24E1:004 Generic TPDO mapping: Entry 4 0x00000000 Mapping U32 1 PH -

0x24E1:005 Generic TPDO mapping: Entry 5 0x00000000 Mapping U32 1 PH -

0x24E1:006 Generic TPDO mapping: Entry 6 0x00000000 Mapping U32 1 PH -

0x24E1:007 Generic TPDO mapping: Entry 7 0x00000000 Mapping U32 1 PH -

0x24E1:008 Generic TPDO mapping: Entry 8 0x00000000 Mapping U32 1 PH -

0x24E1:009 Generic TPDO mapping: Entry 9 0x00000000 Mapping U32 1 PH -

0x24E1:010 Generic TPDO mapping: Entry 10 0x00000000 Mapping U32 1 PH -

0x24E1:011 Generic TPDO mapping: Entry 11 0x00000000 Mapping U32 1 PH -

0x24E1:012 Generic TPDO mapping: Entry 12 0x00000000 Mapping U32 1 PH -

0x24E1:013 Generic TPDO mapping: Entry 13 0x00000000 Mapping U32 1 PH -

0x24E1:014 Generic TPDO mapping: Entry 14 0x00000000 Mapping U32 1 PH -

0x24E1:015 Generic TPDO mapping: Entry 15 0x00000000 Mapping U32 1 PH -

0x24E1:016 Generic TPDO mapping: Entry 16 0x00000000 Mapping U32 1 PH -

0x24E5:001 Process data handling in case of error: Procedure Keep last data [0] general U8 1 P -

0x2540:001

(P208.01)

Mains sengs: Rated mains voltage 230 Ve [0] general U8 1 PC -

0x2540:002

(P208.02)

Mains sengs: Undervoltage warning threshold 0 V * general U16 1 P -

0x2540:003

(P208.03)

Mains sengs: Undervoltage error threshold x V (Read only) general U16 1 - -

* Default seng depending on the size. Firmware version 05.00.00.00

Appendix

Parameter aribute list

674
