• AA Result 7—Coarse data within limits
• AA Result 8—Coarse data deficient
• AA Result 9—Coarse failed to converse
• AA Result 10—Coarse exceeds sense limits
• AA Result 11—Coarse exceeds margin limits
• AA Result 12—Coarse corrections applied
• AA Result 13—Normal exceeds skew limits
• AA Result 14—Coarse exceeds skew limits
• AA Result 15—Coarse new ITU speed
• AA Result 16—AA characterization successfully completed
• AA Result 17—AA characterization
deficient,
using defaults
• AA Result 18—AA manufacturing mode successfully completed
• AA Result 19—AA manufacturing mode deficient, not updating the results
5 Enter the Diagnostics menu, and then navigate to:
Printer setup > EP setup > Toner patch sensor adjust > Full calibration
Note: This triggers the auto align routine (0.42mm—Normal range only).
Action Yes No
Step 1
a From the home screen, touch Settings > Reports > Print
Quality Pages.
b On the CalSet section of the test page, check the color
alignment stat value.
Is the value 0?
Go to step 2. The problem is
solved.
5028
Diagnostic information
237
