e Make sure that the three HVPS contacts (E) move freely and are fully extended.
E
Sensor (media type) removal
1 Remove the transfer module. See “Transfer module removal” on page 334.
2 Open the front door.
3 Remove the screw (A).
5028
Repair information
340
