• Make sure that the index pin (A) behind the transfer module retract arm is properly aligned.
D
Sensor (MPF paper present) removal
1 Remove the waste toner bottle.
2 Remove the motor cover. See “Motor cover removal” on page 273.
3 Remove the right cover. See “Right cover removal” on page 272.
5028
Repair information
322
