3 Remove the four screws (B), and then remove the motor.
B
HVPS removal
1 Remove the transfer module. See “Transfer module removal” on page 334.
2 Remove the controller board. See “Controller board removal” on page 357.
3 Remove the retainer (A).
5028
Repair information
319
