Assembly 14: Miscellaneous parts

Asm-index P/N Units/mach Units/FRU Description Removal procedure

NS 41X0015 1 1 Adapter–N8360 ISP + NFC/BLE dual band ‑‑

NS 40X9652 1 1 Adapter–Fiber gigabit ISP ‑‑

NS 41X0028 1 1 DDR3 RAM, (G2) 2GB, 512Mx32, 204

SODIMM, Unbuered Non‑ECC

‑‑

NS 41X1011 1 1 Font card, Hebrew ‑‑

NS 41X1012 1 1 Font card, Arabic ‑‑

NS 41X1013 1 1 Font card, Simpliﬁed Chinese ‑‑

NS 41X1014 1 1 Font card, Traditional Chinese ‑‑

NS 41X1015 1 1 Font card, Korean ‑‑

NS 41X1016 1 1 Font card, Japanese ‑‑

NS 41X1002 1 1 Forms bar code card ‑‑

NS 41X1006 1 1 Prescribe card --

NS 41X1004 1 1 IPDS SCS TNE card ‑‑

NS 41X1010 1 1 Flash card ‑‑

5028

Parts catalog

441

Lexmark CS725R Service Manual
