550-sheet tray interface cable removal
1
R
emove the tray insert.
2
R
emove the
right cover
. See
“550-sheet tray right
cover removal” on
page
375
.
3
Disconnect the two cables (A),
and then remove the screws (B).
A
B
4
Squeeze, and then push the latches into
the tray base t
o release the cable.
5028
R
epair inform
ation
383
382
384
