3 Remove the five screws (A).
A
4 Remove the right cover from the printer.
5 Remove the right cover from the imaging unit cover. See “Imaging unit cover removal” on page 324.
Motor cover removal
1 Open the toner door.
2 Open the imaging unit cover.
5028
Repair information
273
