3 Disconnect the speaker cable (A), remove the two screws (B), and then remove the speaker.
Control panel base cover removal
1 Remove the badge cover. See “Badge cover removal” on page 283.
2 Remove the number pad cover. See “Number pad cover removal” on page 284.
3 Remove the upper control panel. See “Upper control panel removal” on page 280.
4 Disconnect the speaker cable (A) and sensor cable (B), and then remove the two screws (C).
5028
Repair information
287
