Lexmark CS725R Service Manual

5 Remove the two screws (B).
B
6 Carefully pull the sensor while guiding the black thermistor cable through the hole at the rear of the printer.
7 Disconnect the three cables (C) from the sensor.
Warning—Potential Damage: Press the tab on the white cable while disconnecting it to avoid damage.
C
5028
Repair information
326
