Connector Connects to Pin no. Signal
JPH1 Printhead 1 LADJ_D4_OUT
2I2CDATA_PH
3GND
4I2CCLK_PH
5GND
6SHADE_Y_R2
7LADJ_D2_OUT
8 SHADE_C_R2
9LENA_CMY-_OUT
10 LPOW_Y_OUT
11 GND
12 LPOW_C_OUT
13 BOOST_OUT
14 SHADE_M_R2
15 LADJ_D1_OUT
16 SHADE_K_R2
17 GND
18 LPOW_M_OUT
19 GND
20 LPOW_K_OUT
21 LENA_K-_OUT
22 PH_THERM_ADC
23 GND
24 HSYNC_IN
25 GND
26 YDATA2-
27 YDATA2+
28 GND
29 YDATA1-
30 YDATA1+
5028
Component locations
401
