Lexmark CS725R Service Manual

Connector Connects to Pin no. Signal
CN201 Controller board 1 +25V
2GND
3+25V
4GND
5+25V
6GND
7+25V
8GND
9+25V
10 GND
11 +25V
12 GND
13 +25V
14 GND
15 +25V
16 GND
17 GND
18 GND
19 Zero_Cross
20 Heat_On2
21 Heat_On1
22 Main_On_O
23 Tx_PwrMtr
24 Relay_Drive
25 Ground
26 +6.5V
27 +6.5V
28 +6.5V
29 Rx_PwrMtr
30 Heat_On3
CN1 Fuser 1 AC Common
2AC Out 3
3AC Out 2
4AC Out 1
5028
