Assembly 6: Paper feed
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X7911 1 1Sensor (paper size)
“Sensor (paper size) removal” on
page 312
241X0372 1 1Tray rails
“Tray rail removal” on page 369
3 41X0825 2 1 Support strap --
4 41X0373 1 1 Paper size sensor actuators --
5 41X0956 2 1 Pick roller (tray 1 and MPF) --
6 41X0396 1 1 Media feeder
“Media feeder removal” on
page 373
7 41X0268 1 1 550-sheet tray --
8 41X0374 1 1 Separation block --
5028
Parts catalog
424
