Assembly 7: Paper path 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0390 1 1 Output roll
“Output roll removal” on page 364
2 41X0395 1 1 Fuser drive gear ‑‑
3 41X0001 1 1 Motor (fuser)
“Motor (fuser) removal” on page 318
4 41X0757 1 1 Waste toner bottle idler
gear
“Waste toner bottle idler gear
removal” on page 324
5 41X0450 1 1 Sensor (media type)
“Sensor (media type) removal” on
page 340
6 41X0386 1 1 Deskew rollers
“Deskew rollers removal” on page
342
7 41X0385 1 1 Sensor (input)
“Sensor (input) removal” on page 341
841X0381 1 1Motor (duplex/MPF)
“Motor (duplex/MPF) removal” on
page 315
9 41X0451 1 1 Motor (output)
“Motor (output) removal” on page
297
10 41X0391 1 1 Output gear --
NA 41X0392 1 1 Output drive --
5028
Parts catalog
426
