Assembly 8: Paper path 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X0265 1 1Printhead
“Printhead removal” on page 361
241X0389 1 1Diverter
“Diverter removal” on page 350
3 41X0570 2 1 Sensor (duplex path 1 /
MPF pass‑through)
--
4 41X0388 1 1 Redrive guide
“Redrive guide removal” on page
354
5 41X0384 1 1 Isolation unit
“Isolation unit removal” on page 371
6 41X0758 1 1 Aligner drivetrain kit --
741X0387 1 1Motor (deskew)
“Motor (deskew) removal” on
page 299
8 41X0393 1 1 Motor (black only retract)
“Motor (black only retract) removal”
on page 309
941X0564 1 1Motor (EP drive)
“Motor (EP drive) removal” on
page 296
10 41X0264 1 1 EP gear box
“EP gear box removal” on page 302
NS 41X0897 4 1 Developer hold down
arm
“Developer hold down removal” on
page 363
5028
Parts catalog
428
