Assembly 9: Duplex
Asm-index P/N Units/mach Units/FRUDescription Removal procedure
1 41X0447 2 1 Sensor (fuser buckle /
narrow media)
“Sensors (fuser buckle and narrow
media) removal” on page 294
241X0824 1 1Static brush --
341X0379 2 1Guide spring --
4 41X0378 1 1 Tensioner belt
“Tensioner belt removal” on page
292
5 41X0446 1 1 Sensor (duplex staging) --
641X0377 1 1Pivot shaft
“Pivot shaft removal” on page 291
7 41X0400 1 1 Cable cover --
8 41X0407 1 1 Duplex outer guide
“Duplex outer guide removal” on
page 289
9 41X0376 1 1 Duplex inner guide
“Duplex inner guide removal” on
page 291
5028
Parts catalog
430
