Lexmark CS725R Service Manual

Assembly 12: 550‑sheet tray option 2
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 41X0471 1 1 550-sheet tray interface
cable
“550-sheet tray interface cable
removal” on page 383
2 41X0331 1 1 550-sheet tray controller
board
“550-sheet tray controller board
assembly removal” on page 382
3 41X0466 1 1 Motor (550-sheet tray
pass‑through)
“Motor (550-sheet tray
pass‑through) removal” on page
376
4 40X7911 1 1 Sensor (550-sheet tray
paper size)
“Sensor (550-sheet tray paper size)
removal” on page 380
5 41X0468 1 1 Sensor (550-sheet tray
trailing edge)
“Sensor (550-sheet tray trailing
edge) removal” on page 380
6 41X0396 1 1 550-sheet tray paper feeder
“550‑sheet tray paper feeder
removal” on page 378
7 41X0469 1 1 Sensor (550-sheet tray
index)
“Sensor (550-sheet tray index)
removal” on page 386
8 41X0472 1 1 550-sheet tray empty
sensor actuator
“550-sheet tray empty sensor
actuator removal” on page 384
9 41X0956 1 1 550-sheet tray pick roller --
10 41X0470 1 1 Sensor (550-sheet tray
empty)
“Sensor (550-sheet tray empty)
removal” on page 385
11 41X0373 1 1 550-sheet tray paper size
sensor actuator
--
12 41X0374 1 1 550-sheet tray separator
pad
--
13 41X0334 1 1 Sensor (550-sheet tray
pass-through)
“Sensor (550-sheet tray pass-
through) removal” on page 379
5028
Parts catalog
438
