Lexmark MS610 Series Service Manual

Error code Description Action
242.14 Sheets flushed from paper path either due to feed
error or cartridge error.
Go to “Option tray jam service check” on page 78.
242.15 One or more trays located above the source tray 2 has
been pulled.
242.16 The engine timed out waiting for the tray 2 to report
ready before the 1st pick attempt.
242.17 Page was not properly picked from tray 2. Have not
exhausted all pick retry attempts as there are sheets
committed to the paper path from below.
242.19 Tray 2 fail to feed error. Detected while trying to pick
a sheet, and that leading edge was not detected by
tray sensor.
Go to “Option tray jam service check” on page 78.
242.20 Took too long to ramp up dc feed motor in tray 2.
242.21 Pick motor stall in tray 2.
242.22 Tray 2 pick motor underspeed.
242.24 DC Feed autocompensator stalled on the last pick
attempt in tray 2.
Go to “Option tray jam service check” on page 78.
242.32 Tray not ready.
242.33 Pick received but detected a tray pulled.
242.41 Motor 1 (Pick/Lift) Elevator motor stalled.
242.42 Motor 1 (Pick/Lift) Elevator motor PWM overflow
error (underspeed). Motor underspeed (max PWM
and motor underspeed, typical accordion jam).
Go to “Option tray jam service check” on page 78.
242.43 Motor 1 (Pick/Lift) motor ramp (end ramp - did not
reach speed, typical pack feed paper jam).
242.44 Motor 2 (Separator/Passthru) motor stalled.
242.45 Motor 2 (Separator/Passthru) motor PWM overflow
error (underspeed). Motor underspeed (max PWM
and motor underspeed, typical accordion jam).
242.46 Motor 2 (Separator/Passthru) motor ramp (end ramp
- did not reach speed, typical pack feed paper jam).
242.47 Motor 3 motor stalled. Go to “Option tray jam service check” on page 78.
242.48 Motor 3 motor PWM overflow error (underspeed).
Motor underspeed (max PWM and motor
underspeed, typical accordion jam).
242.49 Motor 3 motor ramp (end ramp - did not reach speed,
typical pack feed paper jam).
243.01 Paper over tray 3 pass thru sensor on warmup.
4514-630, -635, -636
Diagnostic information
73

Lexmark MS610 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 50 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Standard Memory	256 MB
Maximum Memory	1280 MB
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	Ethernet
Input Capacity	Up to 650 pages
Duplex Printing	Yes
