Error code Description Action
244.16 The engine timed out waiting for the tray 4 to report
'ready' before the 1st pick attempt.
Go to “Option tray jam service check” on page 78.
244.17 Page was not properly picked from tray 4. Have not
exhausted all pick retry attempts as there are sheets
committed to the paper path from below.
244.19 Tray 4 fail to feed error. Detected while trying to pick
a sheet, and that leading edge was not detected by
tray sensor.
244.20 Took too long to ramp up dc feed motor in tray 4.
244.21 Pick motor stall in tray 4. Go to “Option tray jam service check” on page 78.
244.22 Tray 4 pick motor underspeed.
244.24 DC Feed autocompensator stalled on the last pick
attempt in tray 4.
244.32 Tray not ready.
244.33 Pick received but detected a tray pulled. Go to “Option tray jam service check” on page 78.
244.41 Motor 1 (Pick/Lift) Elevator motor stalled.
244.42 Motor 1 (Pick/Lift) Elevator motor PWM overflow
error (underspeed). Motor underspeed (max PWM
and motor underspeed, typical accordion jam).
244.43 Motor 1 (Pick/Lift) motor ramp (end ramp - did not
reach speed, typical pack feed paper jam).
244.44 Motor 2 (Separator/Passthru) motor stalled. Go to “Option tray jam service check” on page 78.
244.45 Motor 2 (Separator/Passthru) motor PWM overflow
error (underspeed). Motor underspeed (max PWM
and motor underspeed, typical accordion jam).
244.46 Motor 2 (Separator/Passthru) motor ramp (end ramp
- did not reach speed, typical pack feed paper jam).
244.47 Motor 3 motor stalled.
244.48 Motor 3 motor PWM overflow error (underspeed).
Motor underspeed (max PWM and motor
underspeed, typical accordion jam).
244.49 Motor 3 motor ramp (end ramp - did not reach speed,
typical pack feed paper jam).
4514-630, -635, -636
Diagnostic information
