Page 38 of 88 TP1A072–3 English
Aug 2017
Linx 10 Operating Manual —
Line and message settings
Linx 10
5 Line and message settings
5.1 Basic line settings
The Line Settings screen allows you to create and manage production lines for the printer. A
production line is where messages are printed on products.
For information about advanced line settings, see ‘Advanced Line Settings’ on page 42.
On the Home screen, touch the Line Settings button to display the Line Settings screen.
Figure 30. Line Settings screen
If the Line Sensor option is selected (see ‘Line Sensor’ on page 41), the Line Settings screen appears
as shown in Figure 31.
Figure 31. Line Settings screen: Line Sensor option selected
The following options are available in the ‘Idle’ state and the ‘Jet Running’ state, but not in the
‘Printing’ state.
Line Direction
Speed Mode
button
Trigger to
Printhead
buttons
Encoder Pitch
Set Line Speed/
Distance button
10036
10037
