PECHIMIICAL. DAn
'age 6
Valve Guides (cont.)
Bore in head
Standard
+.0254 mm (.001 in)
+. 0508 mm ( .002 in)
+. 127 mm (.005 in)
lrilet & Exhaust
11.9126/11.9253 mm (.4690/.4695 in)
1 1 .938/11.9507 mm (. 4700/. 4705 in)
11.9634/11.9761 mm (.4710/.4715 in)
12.0396/12.0523 mm ( .4740/. 4745 in)
Outside diameter of guide
Standard
1 1.938/11.9507 mm (. 4700/.4705 in)
+.0254 mm (.001 in)
11.9634/11.9761 mm (.4710/.4715 in)
+. 0508 mm (. 002 in)
1 1.9888/12.0015 mm (.4720/.4725 in)
+. 127 mm (.005 in) 12.065/12.0777 mm ( .4750/.4755 in)
CAMSHAFTS
End float
- Dimension .0254/. 2032 mm (.001/.008 in)
- Controlled by Selective thrust washers
Running clearance
.0254/. 0635 mm (.001/.0025 in)
. i :
.;E
..>.
:; .: CAM FOLLOWERS
. ..
..,#$,
...
Bore in camshaft housings 34.925/34.9402 mm (1.3750/1.3756 in)
Outside diameter
34.904/34.912 mm (1.3742/1.3745 in)
AUXILIARY
SHAFT
Running Clearance
End float
.025/.065 mm
(.000P/.0025 in)
.0127/.0381 mm (.0005/.0015 in)
Balance (inc. flywheel
8 clutsh) ,- ,.,, -.
Within 14.42 gr. cm. (.2 oz in)
Diameter
- Main journal (No. l to 4
inc.) 63.487/63.513 mm (2.4995/2.5005 in)
- Mainjournal(No,5only) 63.500/63.513mm (2.500/2.5005in)
- Crankpin 50.73q50.762 mm (1.995/1.9985 in)
End float
- Dimension .076/.203 mm (.003/.008 in)
ESPRIT
Issue 04/78
