BODY
Page
B20
The recommended methods for removing paint are as follows:
*
1.
Wash off with a slow thinner.
2.
Wet flot with an appropriate grade of paper deperident on the amount of
paint to be removed. Paper heavier than
"
240
"
grade must not be used.
BONNET
(HOOD)
10
REMOVE
1.
Open the bonnet and unscrew the support strut from the borinet, taking
care that the shock
p
roof washer under each screw
is
riot misplaced.
2.
With the
aid
of an assistant, release the bolts securing the bonnet to
the hinge bracket, and remove the bonnet.
(9
KEY
TO
FIG.
5
Bonnet Assembly
Hinge Blade (Single Motor Headlamp System)
Hinge Pin (Single Motor Headlamp System)
Hinge Blade (Two Motor
Headlamp System
-
see BJA for detail)
Support Stay, bonnet
Latch Bracket,
Borin3t Lock
Latch Disc, Bonnet Lock
Grille, Bonnet
Bonnet Seal
Bonnet/Plenum Chamber Seal
Cross Shaft, Bonnet Lock, RHD
Cross Shaft Bracket
Bush and Clip Assembly.
Clevis Pin, Rod
Clevis Pin, Pivot
Rod, Bonnet Lock
Striker, Bonnet Catch
Reinforcement Plate
ESPRIT
lesue
04/78
