TECHNICAL DATA
Page 15
ELECTRICAL EQUIPMENT
Battery Type
- Capacity
- Voltage/Polarity
Headlamps
44 amp hr @ 20 hr Rating
12V Negative
4 - 3" diameter units two in each
hwdlamp pod.
Headlamp
- RHD inner 50 (Main
Sealed beam
outer
60W (Dip) 37.5 (Main)
Sealed beam
- LHD inner
Halogen
H1 and H4
outer
Sealed Beam
Sealed Beam
- North American inner No l
outer No 2
Sidelamp 5W
Front and Rear Indicators 21W
Stop Lamps 21W
Tail Lamps 5W
Number plate lamps 6W
Panel Lamps 3W
S-'
Interior Lamps 6W
Warning Lamps 2W Capless
Reverse Lamps 21W Festoon
AI ternator: Lucas 18 ACR (45 amp)
Starter Motor: Type Lucas
3M100
Drive Pre - engaged
Fuses Located inside the glove box. Seven
circuits ore protected by
foses; headlomps
motor, offside side lights, nearside side
-
lights, ignition controlled circuits, auxiliary
controlled circuits and two permanent live
circuits.
ESPRIT
ISSUC 04/78
