BODY
-
-
Page
663
5mm from inside
Fig.
29
Sealant Application Nozzle
Instructions for Cutting Nozzle
(a)
Cut the nozzle
length to the 73mm dimension.
(b)
Cut into the centre line of the nozzle at the
66mm dimension and
then cut down centre line from the 73mm dimension.
(c)
Check the dimension to the inside face of the material
.is
5mm.
If
not,
enlar
g
e opening by cutting away more material until 5mm
is
reached.
(d)
Cut down to the 55mm dimension and then make the angled cut from
the
66nm to the 55mm dimension.
7.
Pierce membrane in cartridge thread, screw on application nozzle and
,,
insert in cartridge gq.
8.
Extrude a continuous bead of sealant on the perimeter of the glass, using
the edge of the glass
and the shape
of
the nozzle as a guide.
When
extruding the bead of moterial hold the gun at
about 45O to theglass and
leanin
g
sli
g
htly inboard.
This
will give the bead the correct dimensions
and also make the top of the bead
collapse inboard of the glass/body
E
S
P
R
I
T
.
.
