BODY
Page
849
L
FRONT
BUMPER
TO
REMOVE
1
.
Remove both headlamp pod assemblies and disconnect the wires from
both
side/indicotor lamp assemblies. It
is
not necessary to disconnect
the
side/indicator lamp assemblies on car with the Federal
specification.
2.
From inside the headlamp pod accesses and front compartment,
remove the bumper mounting bolts with their washers. Unscrew the
self tapping screws securing the bottom of the
Eur/Domestic front
bumper.
3.
Remove the front bumpers and on Eur/Domestic cars remove the side/
indicator
lamp assemblies from the bumper.
NOTE:
Federal front bumpers are secured with eight bolts and all others are
secured with
2
fixing bolts, the side/indicator lamp fixing screws and
5
self tapping screws along the bottom of the bumper.
1.
Reverse the removal procedure, but first clean the surfaces on the
body which come in contact with bumper and apply
sealant to the
bumper before fitting. Fit the finishing strip.
2.
Reconnect the wires to the side/indicator lamps where applicable
and check the lamps function correctly.
l
3.
Replace headlamp pod ossemblies.
REAR
BUMPER
TO
REMOVE
1.
From inside the engine compartment remove the rear trim panel and
unscrew the bumper mounting bolts and
washers.
2.
Remove the bumper assembly.
NOTE:
Federal rkr bumpers are secured with
6
studs, washers and nuts, and all
other
re&r bumpers are secured with
2
bolts.
ESPRIT
Issue
04/78
