WINDOW OPERATING MOTOR REPLACEMENT
BODY
hge 835
1. Reverse the removal instructions.
DOOR CHECK
STRAP REMOVAL
1.
Remove the door trim panel and the PVC sheeting.
2.
Release the bolt securing the check strap to the door hinge an3 the
two bolts securing the strap to the door
beam. Remove the assembly.
DOOR CHECK STRAP REPLACEMENT
1. Reverse the removal procedure.
DOOR REMOVAL
1.
Remove the door trim panel and partly remove the PVC rheeting.
Disconnect the cables from the door window motor.
2.
Remove the trim ponel on the inside of the door hinge.
3.
With the aid of a second operator, supporting the door, remove the
hinge bolts.
4.
Ease door from its location, pull adiusting shims from between body
and hinges, and remove door assembly complete with hinges.
DOOR REPLACEMENT
1.
Reverse the removal procedure, replacing all parts, and adjust
hinges and lock striker as necessary.
SIDE CAPPING RAIL/FINISHER --
TO REMOVE
r
+
1.
Remove the quarter light by releasing the two bolts securing the stops
I *a
attached to the top inside of the quarter light and lift clear of the
bottom retaining strip.
2.
Drill out the pop - rivets along the inside edge of the capping rail from
the forward edge of the windscreen to the rear edge of the quarter
light.
in*
ESPRIT
ISSW 04/78
