ELECTRICAL EQUlPMlEMT
Page M 14
COLUMN MOUNTED SWITCHES
&
To Remove
1. Disconnect the battery terminals.
-
2.
Remove the steering wtieel (see Section 'H').
3.
Rslease the screw from the underside of the column shroud and remove shroud
by pulling off from column.
4.
Release the bolts securing the switches to the column, disconnect the switch
cables, and remove switches.
To Replace
l
1.
Reverse the removal procedure, referring to the Wiring Diagrams for correct
cable replacement.
b
To Remove
1.
The ignttlon switch can only be replaced in conjunction with the steering
lock
assembly - see Section H.
To Replace
1.
Revens the removal procedure, referring to the Wiring Diagromr for correct
l
cable replacement.
C /
RADIO
To Remove
1.
Rmove the radio control knobs and front ponel.
2.
Disconnect radio live and earth cables, orld oerial lead and withdraw the
radio from the rear and ease downwards by the side
of the chassis tunnel
a remove the centre tunnel top.
To Replace
1.
Replacement is a direct reversal of the removal procedure. Refer to the
Wiring Diagrams for correct cable replacement.
ESPRIT
Issue 04/78
