FUEL
SVSTEbI
Page
L6
6.
Release the clips and remove the rubber hoses connecting the fuel tonks to
the filler necks, first disconnect
:he breother pipes from the fillet necks.
7.
From each tank, remove the two bolts securing the tank in the body. One
bolt is in the forward port of the
rear wheel arch and the other belt on the
inside (chassis side).
To Replace
1.
Reverse the removal instructions.
FUEL
TANK
SENDER
UNIT
To Remove
1.
Remove the engine cover.
2.
Remove the battery.
3.
Remove
RH
engine compartment floor panel to gain access to the top of the
RH
fuel tank.
4.
Visconnect sender unit electrical connections.
5.
Unscrew the three screws securing the sender unit to the top of the tank.
To Replace
1.
Fit a new sealing ring and coat the threads of the three retaining screws with
Avdelbond
-
A
-
115 or similar. Ensure ali threads are fitted, but take care
that excess does not fall into tank. Tighten screws to
5
to
7
lbs/ft
only
(hand tight), do not
overtGhten as the $osket will distort and screw threads
may strip.
2.
Reverse the removal instructions from
4
to
1.
%
FUEL
GAUGE
Detailed instructions for removal and replacement of the fuel gauge are given in
Section
M
under the heading
INSTRUMENTS.
FUEL
PUMP
To Remove
1.
Disconnect the battery.
2.
Remove the pipes from the pump which
is
accessible from under the LH side
of the vehicle on the back of the engine bulkhead. Some vehicles have the
petrol pump fitted under the
RH
engine compartment floor ponel. Insert a
ESPRIT
plug in the pipe from the tanks, otherwise the fuel will drain out.
Issue
04/78
