Fire mode operation may result in inverter malfunction. Note that if AD 83 Fire mode count
is not "0m" the warranty is voided.
Ad.81
Fire
Mode
frequency
Fire mode
frequency
reference
The frequency set at Ad. 81 (Fire mode frequency) is used
for the inverter operation in Fire mode. The Fire mode
frequency takes priority over the Jog frequency, Multi-step
frequencies, and the keypad input frequency.
Dr.03 Acc
Time /
Dr.04
Dec Time
During Fire Mode operation, the inverter accelerates for
the time set in Dr 03. Acc Time. If the Px terminal input set
as Fire Mode input becomes Off status, the inverter
decelerates for the time set in Dr 0.4. Dec Time until the
operation is ended.
Some fault trips are ignored during Fire mode operation.
The fault trip history is saved, but trip outputs are disabled
even when they are configured at the multi-function output
terminals.
Fault trips that are ignored in Fire mode
BX, External Trip, Low Voltage Trip, Inverter Overheat,
Inverter Overload, Overload, Electrical Thermal Trip,
Input/Output Open Phase, Motor Overload, Fan Trip, No
Motor Trips, and other minor fault trips.
For the following fault trips, the inverter performs a Reset
and Restart until the trip conditions are released. The retry
delay time set at PR. 10 (Retry Delay) applies while the
inverter performs a Reset and Restart.
Fault trips that force a Reset Restart in Fire mode
Over Voltage, Over Current1 (OC1), Ground Fault Trip
The inverter stops operating when the following fault trips
occur:
Fault trips that stop inverter operation in Fire mode
H/W Diag, Over Current 2 (Arm-Short)
