LSIS G100 User Manual

Code
Comm.
Addres
s
Name
Setting Range
Initial
Value
Prop
erty*
V/
F
S
L
Ref.
52
KEB-1 Select
p.140
In-84
0h1554
Multi-function
input terminal
On filter
selection
P5–P1
1 1111
31
O
O
O
p.102
0
Disable(Off)
1
Enable(On)
In-85
0h1555
Multi-function
input terminal
On filter
0–10000 (ms)
10
O
O
O
p.102
In-86
0h1556
Multi-function
input terminal
Off filter
0–10000 (ms)
3
O
O
O
p.102
In-87
0h1557
Multi-function
input terminal
selection
P5 – P1
0 0000
32
X
O
O
p.102
0
A contact (NO)
1
B contact (NC)
In-88
0h1558
Selects the
NO/NC
operation
command
0
NO
0
X
O
O
1
NO/NC
In-89
0h1559
Multi-step
command
delay time
1–5000 (ms)
1
X
O
O
p.71
In-90
0h155A
Multi-function
input terminal
status
P5–P1
0 0000
-
O
O
p.102
0
release(Off)
1
Connection
(On)
In-99
0h1563
SW1
(NPN/PNP),
status
Bit
0–1
0
-
O
O
-
0
NPN
1
PNP
