LSIS G100 User Manual

3.2.2 Navigating Directly to Different Codes (Jump Codes)
The following example details navigating to code dr. 95, from the initial code in the
Drive group (dr. 0). This example applies to all groups whenever you would like to
navigate to a specific code number.
Step
Instruction
Keypad Display
1
Ensure that you are currently at the first code of the Drive
group (dr.0).
2
Press the [ENT] key.
Number "9" will flash.
3
Press the [▼] key and change the ones' place number to
"5", so the destination code is "95".
4
Press the [MODE] to move to the tens' place.
The cursor will move to the left and "05" will be displayed.
At this time, the number "0" will be flashing.
5
Press the [▲] key to change the tens' place number to
"9", so the destination code is "95".
6
Press the [ENT] key.
Code dr.95 is displayed.
