LSIS G100 User Manual

5.16 2
nd
Motor Operation
The 2nd motor operation is used when a single inverter switch operates two motors.
Using the 2nd motor operation, a parameter for the 2nd motor is set. The 2nd motor is
operated when a multi-function terminal input defined as a 2nd motor function is
turned on.
Group
Code
Name
Setting
Setting
Range
Unit
In
65–69
Px terminal
setting options
26
2nd
Motor
0–52
-
2
nd
Motor Operation Setting Details
Code and
Features
Description
In.65–69 Px
Define
Set one of the multi-function input terminals to 26 (2nd Motor) to
display M2 (2nd motor group) group. An input signal to a multi-function
terminal set to 2nd motor will operate the motor according to the code
settings listed below. However, if the inverter is in operation, input
signals to the multi-function terminals will not read as a 2nd motor
parameter.
Pr.50 (Stall Prevent) must be set first, before M2.28 (M2-Stall Lev)
settings can be used. Also, Pr.40 (ETH Trip Sel) must be set first,
before M2.29 (M2-ETH 1min) and M2.30 (M2.ETH Cont) settings.
Parameter Setting at Multi-function Terminal Input on a 2nd Motor
Code and
Features
Description
Code
Description
M2.04 Acc Time
Acceleration time
M2.16 Inertia Rt
Load inertia rate
M2.05 Dec Time
Deceleration time
M2.17 Rs
Stator resistance
M2.06 Capacity
Motor capacity
M2.18 Lsigma
Leakage inductance
M2.07 Base Freq
Motor base frequency
M2.19 Ls
Stator inductance
M2.08 Ctrl Mode
Control mode
M2.20 Tr
Rotor time constant
M2.10 Pole Num
Pole number
M2.25 V/F Patt
V/F pattern
M2.11 Rate Slip
Rated slip
M2.26 Fwd Boost
Forward Torque boost
M2.12 Rated
Curr
Rated current
M2.27 Rev Boost
Reverse torque boost
M2.13 Noload
Curr
No-load Current
M2.28 Stall Lev
Stall prevention level
M2.14 Rated
Volt
Motor rated voltage
M2.29 ETH 1min
Electronic thermal 1
minute rating
M2.15 Efficiency
Motor efficiency
M2.30 ETH Cont
Electronic thermal
