3.3.3 Jog Frequency Configuration
The following example demonstrates how to configure Jog Frequency by modifying
code 11 (Jog Frequency) in the Drive group from 10.00 Hz to 20.00 Hz. You can
configure the parameters for different codes in any other group in exactly the same
way.
Step
Instruction
Keypad Display
1
Go to code 11 (dr.11) in the Drive group.
2
Press the [ENT] key.
The current Jog Frequency value (10.00) for code dr.11 is
displayed.
3
Press the [MODE] key 3 times to move to the tens' place
value.
"1" in the tens' place will flash.
4
To make the target value "20.00", press the [▲] key to
change the tens' place value to "2", and then press the
[ENT] key.
The selected value will flash on the display.
5
Press the [ENT] key again to save the changes.
Code dr.11 will be displayed. The parameter change has
been completed.
