Note
The following are values and functions that are applied to address 0h0322:
Setting
Function
0h0001
Forward operation (Fx)
0h0003
Reverse operation (Rx)
0h0000
Stop
7.2.6 Saving Parameters Defined by Communication
If you turn off the inverter after setting the common area parameters or keypad
parameters via communication and operate the inverter, the changes are lost and the
values changed via communication revert to the previous setting values when you
turn on the inverter.
Setting address 0h03E0 to 0 and then setting it again to 1 via communication allows
the existing parameter settings to be saved. However, setting address 0h03E0 to 1
and then setting it to 0 does not carry out the same function.
7.2.7 Total Memory Map for Communication
Communication Area
Memory Map
Description
Communication common
compatible area
0h0000–0h00FF
iS5, iP5A, iV5, iG5A compatible area
Parameter registration type
area
0h0100–0h01FF
Areas registered at CM.31–38 and
CM.51–58
G100 communication
common area
0h0300–0h037F
Inverter monitoring area
0h0380–0h03DF
Inverter control area
0h03E0–0h03FF
Inverter memory control area
0h0400–0h0FFF
Reserved
0h1100
dr Group
0h1200
bA Group
0h1300
Ad Group
0h1400
Cn Group
0h1500
In Group
0h1600
OU Group
0h1700
CM Group
0h1800
AP Group
0h1B00
Pr Group
0h1C00
M2 Group
