LSIS G100 User Manual

7.5 Compatible Common Area Parameter
The following are common area parameters compatible with iS5, iP5A, iV5, and iG5A.
Comm.
Address
Parameter
Scale
Unit
R/W
Assigned Content by Bit
0h0000
Inverter model
-
-
R
16: G100
0h0001
Inverter capacity
-
-
R
0: 0.75kW, 1: 1.5kW, 2: 2.2kW,
4: 5.5kW, 5: 7.5kW,
6: 11kW, 7: 15kW, 8: 18.5kW,
9: 22kW
256 : 0.4kW, 259: 4.0kW
0h0002
Inverter input voltage
-
-
R
0: 220 V level, 1: 440 V level
0h0003
Version
-
-
R
(E.g.) 0h0100: Version 1.00
(E.g.) 0h0101: Version 1.01
0h0004
Reserved
-
-
R/W
-
0h0005
Target frequency
0.01
Hz
R/W
-
0h0006
Operation command
(option)
-
-
R
B15
Reserved
B14
0: Keypad Freq
1: Keypad Torq
2-16 Terminal block
multi-step speed
17: Up, 18: Down
19: STEADY
22: V1, 24: V0, 25: I2
26: Reserved
27: Built-in 485
28: Communication
option
30: JOG, 31: PID
B13
B12
B11
B10
B9
B8
0: Keypad
1: Fx/Rx-1
2: Fx/Rx-2
3: Built-in 485
4: Communication
option
B7
B6
R/W
B5
Reserved
B4
Emergency stop
B3
W: Trip initialization
(01)
R: Trip status
B2
Reverse operation (R)
B1
Forward operation (F)
B0
Stop (S)
0h0007
Acceleration time
0.1
sec
R/W
-
0h0008
Deceleration time
0.1
sec
R/W
-
