LSIS G100 User Manual

Group
Code
Name
Setting
Setting Range
Unit
Pr
81
Low voltage trip
decision delay time
0.0
0–60
sec
OU
31
Multi-function relay
1 item
11
Low Voltage
-
-
33
Multi-function relay
2 item
Low Voltage Fault Trip Setting Details
Code and
Features
Description
Pr.81 LVT Delay
If the code value is set to 11 (Low Voltage), the inverter output is
blocked first when the low voltage trip occurs and the trip is handled
after a set time.
You can generate a warning signal on the low voltage trip using the
multi-function relay. The LVT Delay time is not applied on the warning
signal.
6.3.4 Output Block by Multi-Function Terminal
When the multi-function input terminal is set as the output block signal terminal and
the signal is input to the terminal, then the operation stops.
Group
Code
Name
Setting
Setting Range
Unit
In
65–69
Px terminal setting
options
5
BX
-
-
Output Block by Multi-Function Terminal Setting Details
Code and
Features
Description
In.65–69 Px
Define
When the operation of the multi-function input terminal is set to 5 (BX)
and is turned on during operation, the inverter blocks the output and
‘BX’ is displayed on the keypad display.
While ‘BX’ is displayed on the keypad screen, the inverter’s operation
information including the operation frequency and current at the time of
BX signal can be monitored. The inverter resumes operation when the
BX terminal turns off and operation command is input.
6.3.5 Trip Status Reset
